Vertongen Pentho Compact 3

Chassis:
Construction:           ZKF Chassis, combined self supporting chassis with
                                a cage construction.
Safety screen:         Pieces of hard and dust repelling polycarbonate on a
                                rail with wheels.  Movement with catch plates
Security:                  conform CE.
dimensions:             2200 x 1700 x 1600 mm
total extraction:        1 x  80 mm; 3 x  150 mm

Table
table mounting:         vertically attached; extra solid
movement:               manually; automatic movement option
table:                        swivelling +60º to -60º; fixed in height ;
backing wood:          clamp for straight backing wood; round backing wood
                                 (optional - fitted to stock machine)
Clamps :                   quick acting clamp vert.; pneumatic clamps vert. option
                                 (fitted to stock machine).
length fence:             2,4 to 3,4 m.; large back stops option;
                                  elec. dig. reading option
dimensions:              400 mm x 600 mm

Cut off Saw
Motor:                       2,2 kW - 3000 rpm
Adjustment:              hor. 20 - 155 mm - cut-off capacity 150 mm
Tool:                         noise reduced saw included - diam. 400 mm
Extraction:                diam. 80 mm
Positioning:               manual on slide bearings
reading :                   mechanical; laser option

Tenoning heads
Motor :                     2 x 2,2 kW
RPM:                       4500
suspension:             slide bearings
reading:                   mechanical digital counter on front of machine
Tooling :                  160 mm; length 145 mm; Exchangeable blades
Tenon heads           included
.extraction:               2 x 150 mm diameter
movement:               horizontally upper -55 / +25 mm; lower -55 / +0 mm
                                 vertically upper 0 - +150 mm; lower -5 - +115 mm

Vertical spindle
Motor :                     5,5 kW; 7,5 kW option
RPM:                       4000
suspension:             dove tail
reading:                   mechanical digital counter on front of machine
movement:              horizontally 150 mm; vertical -150 - +25 mm
Spindle length:        160 mm; 200 mm option
Spindel  :                 40 or  50 mm
Tool  :                      max.  350 mm
extraction:               150 mm diameter
